Turnstile TS2000 Plus Series

TS2000 Plus Series is a dual-lane tripod turnstile system designed for high-traffic access control areas. Built from premium SUS304 stainless steel and offering semi-automatic mechanism control, it delivers a perfect balance between security, performance, and aesthetics. Ideal for business centers, industrial facilities, government buildings, and educational institutions.

✅ Purpose: Manage bi-directional pedestrian access
✅ Application areas: Office buildings, schools, factories, public infrastructure, and more
✅ Advantages:

Robust dual-lane design for efficient throughput
Advanced integration with biometric & RFID systems
Emergency auto-drop arm function
Compact and elegant design for limited space
High MTBF and quick maintenance capability

SKU: TS2000 Plus

2900,00 ₾

Add to compare

სპეციფიკაცია

⚙️ Technical Specifications – TS2000 Plus Series

Category	Specification
Structure Type	Dual-lane tripod turnstile
Lane Width	550 mm
Barrier Type	Rotating tripod arms
Barrier Width	500 mm
Drive Mechanism	Semi-automatic
Flow Rate	RFID: up to 25 persons/min Fingerprint: up to 20 persons/min
Barrier Movement	Rotation
Pass Direction	Bi-directional
Visual Indicator	Green (steady) – Normal use Red (steady) – Barrier closed
Audio Indicator	Internal buzzer
Lid Material	SUS304 stainless steel
Chassis Material	SUS304 stainless steel (1.2 mm thick)
Chassis Color	Silver-gray
Barrier Material	SUS304 stainless steel
Authentication Options	Undermount: RFID / Fingerprint
Credential Devices	RFID: ProID Series, KR Series Fingerprint: FR1200 / FR1500S
Access Controllers	Recommended: C3-200 Pro Plus / InBio260 Pro Plus Optional: depends on fitting dimensions
Mainboard Functions	Barrier open time, access mode setting
Communication Interfaces	RS485, Fire alarm input (voltage-free relay)
Software Compatibility	ZKBio CVAccess / ZKBio CVSecurity (based on controller)
Security Features	Anti-tailgating, fire alarm fail-safe (drop arm on power-off)
Emergency Mode	Supported
Power Supply	AC 110V / 220V @ 50–60Hz, DC 12V
Power Consumption	Standby: 10VA Operating: 40VA
Noise Level	Less than 65 dB
MTTR	Less than 60 minutes
MCBF	2 million cycles
Ingress Protection	IPX4
Operating Temperature	-20°C to +70°C
Operating Humidity	0% – 85% RH (Non-condensing)
Product Dimensions (L×W×H)	780 × 750 × 1000 mm
Packing Dimensions (L×W×H)	380 × 520 × 1100 mm
Footprint	100 × 420 mm
Weight	Net: 20 kg Gross: 25 kg
Security Level	Medium
Certifications	CE, FCC, UKCA, ISO 9001
Installation Method	Pre-assembled, flat & level floor required Optional base plate for unfinished floors
Delivery	Pre-assembled unit
Environment	Indoor / Outdoor (sheltered only)
